Description
KDC-BT500U – CD MP3 USB Stereo Bluetooth iPhone Android Player
Key Features
4 x 50W Max output power
1 RCA Preout, 2,5V
Full detachable faceplate
iPod / iPhone Direct Control
Android MSC / AOA2 compatible
TuneinRadio/AUPEO App mode
MP3, WMA, AAC, WAV & FLAC playback
Red Key & White Display Illumination (LED)
FM with RDS & AM tuner
Bluetooth bult-in, (HFP 1.6 & A2DP)
General Features
DIN Size 1 DIN
Detachable Faceplate
Key Illumination Red
Rotary Encoder & Control Knob
Music Search function
Accent key Telephone
Back-up Memory Radio presets
Attenuator with Smooth Volume Return Yes
Digital Clock (24H) Yes
All-off Select (20/40/60 minutes) Yes
Built-in Connector Molex 16 pin
Firmware upgreadable
Display Features
Display Type Liquid Crystal Display (LCD)
Display Layout 13 characters/digits
Display Illumination White LED
Dimmer Control Manual / Set by Timer
Dimmer Timer Yes
Brightness control Display (32 steps)
Demo Mode
Menu text in selectable language English, Spanish, Russian
TAG Language Display English, Spanish, Russian, Greek & Turkish
Cosmetics features
Triangle Illumination Red
Key illumination Red
Display illumination White LED
Front terminals dust cover Yes
Tuner Features
Radio Data System
Radio Text Plus
Traffic Information Yes
FM Reception Yes
AM (MW/LW) Reception
AF Regional Selectable: AF/AF Reg/OFF
Local search Yes
Auto TP search
Presets24 Presets (18FM / 3LW / 3MW)
Mixed preset memory (FM & AM) 6 presets
Automatic Memory Entry (AME)
Tuning mode (Auto1 / Auto2 / Manual)
FM Stereo / Mono Selector
Preset memory w/o back-up power
Enhanced Other Networks Function (EON)
CE_Playable Audio file
AAC (*.m4a) files are playable from CD/USB
MP3 files are playable from CD/USB
WMA (.wma) files are playable from CD/USB
WAV (.wav) files are playable from USB
FLAC files are playable from USB
CD Features
Compatible with Kenwood Music Editor Lite
CD Text with special Character Support English, Spanish, Russian, Greek, Turkish
D.A.C. processing 24 bit
0 bit Mute
USB Features
USB Type USB 1.1/USB 2.0 Full Speed
Drive Change
Kenwood Music Editor Lite Compatible
Kenwood Music Control App for Android
Android Open Accessory support (AOA) V 2.0
Repeat/Scan/Random search Yes
Repeat / Random Play Yes
Resume play Yes
Time code display Yes
1,5A charge (BC 1.2) Yes
iPod Features
Made for iPod & iPhone *
USB Direct Control (Audio, 1 wire, Lightning-connector)
Alphabet search
Direct Search Yes
iPod EQ Mode Yes
Control by hand
App & iPod control mode
iAP over Bluetooth Yes
Reverse browsing Yes
Works with iPod Classic * 80G, 120G & 160G
Works with iPod Video * 5th/6th generation
Works with iPod Touch * 2nd/3rd/4th & 5th*** generation
Works with iPod Nano * 3rd/4th/5th/6th/7th generation
Works with iPhone * 3G, 3GS,4,4S, 5, 5S, 5C, 6, 6Plus
Bluetooth Auto Paring for iPhone Yes
Battery charge + power control Yes
1A current capability
Always update to latest Apple firmware
** Apple Lightning – 30 pin adapter required
*** In case of Apple Unit with Lightning Connector only Audio playback Yes
Audio Features
Maximum Output Power 50W x 4
MOSFET Power IC Yes
Auxiliary input Front Mini-jack
Pre-out 1 RCA
Pre-out Output Level 2.5V
Preout Rear / Subwoofer Switchable
Subwoofer Reference Level Adj. Yes
2-Way X’over network Yes
3-Way x’over (bi-amp connection) Yes
Balance/Fader/Loudness Control Yes
Loudness Control Off/Low/High
Bass Boost Circuit Off/+1/+2/+3/+4/+5
Equalizer built-in Yes, 13 band with 8 presets
Low- & High-pass Filter Yes
Kenwood Sound Reconstruction Yes
Space Enhancer Yes
Realizer Yes
Drive EQualizer
Extra EQ
Bluetooth General Features
Hands Free Profile (HPF) V1.6
Hands Free Profile with High Sound Quality HFP V1.6
Advanced Audio Distribution Profile (A2DP)
Serial Port Profile (SPP)
Phonebook Access Profile (PBAP)
Audio/Video Remote Control Profile (AVRCP) V 1.5 with Tag browse
Easy pairing function Yes
iPhone & Android automatic pairing via USB
Dual phones connection
Voice Control Yes
Noise Canceller Yes
Echo Canceller Yes
Phone device status display Yes
Signal strength display Yes
Remaining battery display Yes
High-quality noise canceling microphone Yes, (rear wired)
Bluetooth firmware upgradeable
depends on phone model/make & Kenwood unit
Connectivity
iPod Digital Connection (1 Wire) Yes
Front USB & AUX Input
DC-Cord Molex to ISO
Power Control (P.CON) wire
2-way (Tel/Navi) mute wire
FM Antenna Input Yes
External microphone input (mini-jack) Yes
Tuner Specifications
FM range: 87.5Mhz – 108MHz (50Khz step) Yes
FM Usable Sensitivity 0.71μV/75ohm (S/N 26dB)
FM Quieting Sensitivity 2μV/75ohm (S/N 46dB)
FM Frequency Response 30Hz ~ 15kHz (± 3dB)
FM Signal to noise ratio (Mono) 64dB
FM Stereo Separation (1kHz) 40dB
MW range: 531kHz – 1611kHz (9kHz step) Yes
MW Usable Sensitivity 28.2μV
LW range: 153kHz – 279kHz (9kHz step) Yes
LW Usable Sensitivity 50μV
CE_CODEC_Specs
MP3 Format MPEG 1/2 Audio Layer 3-Files
WMA Format Compliant with Windows Media Audio
AAC Format AAC-LC “.m4a” files
WAV Format RIFF waveform Audio Format (only for LinearPCM)
FLAC Format all FLAC files
CD Specifications
Laser Diode GaAIAs
Digital Filter(D/A) 8 Times Over Sampling
Digital/Analogue Converter 24 Bit
Spindle Speed 500 ~ 200rpm (CLV: 1 times)
Wow & Flutter below measurable limit
Frequency Response 20Hz ~ 20kHz (±1dB)
Total Harmonic Distortion 0.01% (1kHz)
Signal to Noise Ratio 105dB (1kHz)
Dynamic Range 90dB
Channel Separation 85dB
USB Specifications
USB Version compatibility USB 1.1/2.0 full speed
File System FAT 32/16/12
Maximum Supply current 1000mA
Audio Specifications
Maximum Power 50W x 4
Output Power (DIN45324,+B=14.4v) 30W x 4
Preout Level 2500mV / 10kOhm,
Preout Impedance ≤ 600Ohm
Speaker Impedance 4Ohm ~ 8Ohm
AUX Frequency Response 20Hz ~ 20kHz (±1dB)
AUX Maximum Input Voltage 1000mV
AUX Input Impedance 30kOhm
Graphical Equalizer 13-Band
G. EQ. Frequency (Hz) 62,5Hz – 16kHz
G. EQ. Gain (dB) -8/-7/-6/…/-1/0/1/…/6/7/8
Subwoofer Level (dB) -50 dB to +10dB
Bluetooth specifications
Technology bluetooth V2.1+EDR/Bluetooth V3.0
Frequency 2.402 – 2.48 GHz
Output power +4dBm(max), 0dBm (AVE) power class 2
Maximum range Line of sight approx. 10 meter
Accessories
Release keys 2 pieces
Escutcheon Yes
Installation Sleeve Yes
DC cord (Molex to ISO) 25 cm
Handsfree Microphone with 3 m cable
Multi-Language Instruction Manual Included Quick-Guide
Manuals Downloadable
General Specifications
Operating voltage 14.4V (10.5 ~ 16V Allowable)
Maximum Current Consumption 10A
Dimensions (WxHxD) 182 x 53 x 159mm
Weight 1300gr
Operation Temperature Range -10°C ~ 60°C
